| Part Number |
3590060 |
| Previous Part Number |
3529761, 3529762, 3537939, 3537940, 3590061, 3802359, 3802359RX, 3802808, 3802808RX, 4033631 |
| OE Number |
65091007188, 65.09100-7188, 65,09100-7188 |
| Year |
1997-06 |
| Description |
Marine |
| Manufacturer Part Number |
3590061 |
| CHRA |
3545694 (3545694H) |
| Turbo Model |
H2D, H2DM, H2D-9351N/HA20S3 |
| Engine |
D1146M, D114 6M |
| Engine Manufacturer |
Daewoo |
| Bearing Housing |
3525199 (Oil Cooled)(1900011204) |
| Turbine Wheel |
3522232 (3528251)(Ind. 85.95 mm, Exd. 72. mm, Trm 12.37, 11 Blades)(1152302435, 1100016086) |
| Rotor Assembly |
3545726 |
| Comp. Wheel |
3524808 (352480800)(Ind. 63.42 mm, Exd. 93.92 mm, Trm 12.54, 8+8 Blades, Superback)(1200016361) |
| Back plate |
62564 (3762564, 167543)(1253300300, 1800016038) |
| Heat shield Number |
3529846 (3533038)(1153052340, 2030016003) |
| Repair Kit |
3545653 (1152302750, 5000020017) |
| Turbine Housing (Water Cooled) |
3526038 (3537938) |
| Compressor Cover |
3525003 |
| Gasket Kit |
3545653 (1152302750) |
| Manufacturer |
HOLSET |
